| Number | Image Sample | Sheets | Description | Architect | Builder/Developer | Client | Address | Town/Development | Notes | Date |
|---|---|---|---|---|---|---|---|---|---|---|
| PEW.RHS.1.1 | Sample | 7 | House | Adams, Alexander M., del. | Lengel, J. M., dev. | Hoffner, Alford W., Jr. | Sugartown Farms Willistown, Pa. |
|||
| PEW.RHS.1.2 | 2 | Sewer connection | Smith, Walter B., dev. | 6, 8, and 20 St. Pauls Road, Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #'s 2 16 19 27 See also house #4 for Walter B. Smith |
||||
| PEW.RHS.1.3 | Sample | 2 | House | Heacock and Hokanson | Smith, Walter B., dev. | Bass | 17 St. Pauls Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Plan also used at Wynnewood Manor and built on City Ave., near the Bala train station. On verso the annotation "Bass" has been crossed out. | |
| PEW.RHS.1.4 | Sample | 3 | Box stalls | Lengel, J.D., bldr. | Bryn Mawr Horse Show Association | 1931 | ||||
| PEW.RHS.1.5 | Sample | 1 | Seats for tennis court | Paul, Oglesby, lands. archt. | Mr. E.H. Fitler | Rosemont, Pa. | ||||
| PEW.RHS.1.6 | Sample | 1 | Store (Temporary Front) | Smith, Alan G., bldr | D.F. Donohoe, Inc. | 63 Lancaster Ave., Ardmore, Pa. | 1936 | |||
| PEW.RHS.1.7 | Sample | 1 | Star Sewage Disposal System | Sewage treatment system | Brush, Franklin C. | Phoenixville, Pa. | ||||
| PEW.RHS.1.8 | 1 | Tenant's cottage | Page, George Bispham | Stuart, Marion P., Mrs. | Villa Nova, Pa. | 1945 | ||||
| PEW.RHS.1.9 | Sample | 2 | House | Heacock and Hokanson | Smith, Walter B., dev. | Mrs. Peters | 35 St. Paul's Rd.,Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #21 | |
| PEW.RHS.1.10 | Sample | 2 | House | Addis and Ashmead | Lathrop, W.H. | Ithan, Pa. | Architect's job no. 1631. | 1950 | ||
| PEW.RHS.1.11 | Sample | 2 | House (Bathroom additions) | Lengel, J.D., bldr. | Genay, T.B. | |||||
| PEW.RHS.1.12 | Sample | 1 | Garage (Details of bench in porch of garage) | Boyd, D. Knickerbacker | Salen, James | Rosemont, Pa. | Architect's work no. 1007 | 1918 | ||
| PEW.RHS.1.13 | Sample | 1 | School (Alt. and add.) | Boyd, D. Knickerbacker | Wayne, Pa. | Architect's work no. 382. | 1900 | |||
| PEW.RHS.1.14 | Sample | 1 | Details for trolley shelter | Sears, Thomas W., lands. archt | Dunwoody Home | Newtown Square, Pa. | 1926 | |||
| PEW.RHS.1.15 | Sample | 8 | House | Tax, A. M., Mrs. | ||||||
| PEW.RHS.1.16 | 1 | Barn (survey of existing conditions) | Sears, Thomas W., lands. archt. | Clothier, Isaac H., Jr. | Radnor, Pa. | |||||
| PEW.RHS.1.17 | 1 | Barn (Addition) | Lengel, J. D., bldr. | Clothier, Isaac H., Jr. | Radnor, Pa. | |||||
| PEW.RHS.1.18 | Sample | 1 | Stables (repairs) | Karcher and Smith | Lengel, J. D., contr. | Clothier, Isaac H. Jr. | Radnor, Pa. | 1926 | ||
| PEW.RHS.1.19 | 2 | House (small) | Trumbauer, Horace | Smith, Walter B., dev. | Smith # 77 | |||||
| PEW.RHS.1.20 | 1 | Apartments over garages | Trumbauer, Horace | 2031 and 2035 N[orth] 63rd Street Overbrook | Smith #65 | |||||
| PEW.RHS.1.21 | Sample | 2 | House | Boyd, D. Knickerbacker | Smith, Walter B., dev. | Walton, Charles S. | Smith #85; Architect's work no. 436 | 1902-1904 | ||
| PEW.RHS.1.22 | Sample | 1 | Garage | Smith, Alan G., dev. | Wynnewood, Pa. | Wynnewood Manor | ||||
| PEW.RHS.1.23 | Sample | 2 | Special angle frame for leaded glass ventilator | David Lupton's Sons Co. | Lengel, J. D., bldr. | 1930 | ||||
| PEW.RHS.1.24 | 1 | House | Lengel, J. M., dev. | |||||||
| PEW.RHS.1.25 | Sample | 1 | Garage at house no. 2 | Lengel, J. D., bldr. | Radnor Realty Co. | |||||
| PEW.RHS.1.26 | Sample | 5 | House (one of a group of six houses) | Reeser, Victor | Smith, Walter B., dev. | Narberth, Pa. | Smith #129 | 1918 | ||
| PEW.RHS.1.27 | Sample | 1 | Greenhouse | Lord and Burnham Company | Smith, Walter B., dev. | 6490 Woodbine Ave., Overbrook Philadelphia Pa. |
Smith #117 | 1915 | ||
| PEW.RHS.1.28 | Sample | 2 | House | Heacock and Hokanson | Smith, Walter B., dev. | 221 Wynnewood Ave. & 118 Mill Rd., Wynnewood, Pa. |
Wynnewood Manor | Smith #44 | 1906 | |
| PEW.RHS.1.29 | Sample | 1 | House (Alterations) (Plan for converting boiler house into residence) | Heacock and Hokanson | Smith, Walter B., dev. | Wynnewood, Pa. | Wynnewood Manor | Smith #45 | 1921 | |
| PEW.RHS.1.30 | Sample | 1 | Garage | Heacock and Hokanson | Smith, Walter B., dev. | Wynnewood, Pa. | Wynnewood Manor | Smith #46 | 1906 | |
| PEW.RHS.1.31 | 1 | Apartment house | Pollock, Robert W. | Smith, Walter B., dev. | Athens Ave. and Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #26 | 1917 | ||
| PEW.RHS.1.32 | Sample | 2 | House (Extension to living room) | Lengel, J. M., del. | McKinley, Mrs. R.S. | Wayne, Pa. | 1910 | |||
| PEW.RHS.1.33 | Sample | 3 | Masonic Hall | Shaw, J. William | Wayne, Pa. | 1892 | ||||
| PEW.RHS.1.34 | Sample | 1 | Sign: "Orders taken here for domestic rabbit meat" [Sketch for signage] |
A.R. Brand | ||||||
| PEW.RHS.1.35 | Sample | 4 | Cottages (Gardener's cottage & chauffer's cottage) | Lengel, J.D., bldr. | Sinkler, James M.R. | Sugartown, Pa. | 1930 | |||
| PEW.RHS.1.36 | 1 | Apartment house (proposed) | Trumbauer, Horace | Smith, Walter B., dev. | Athens Ave. and Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #25 | 1910 | ||
| PEW.RHS.1.37 | Sample | 1 | [Built-in corner cabinet.] | 1925 | ||||||
| PEW.RHS.1.38 | Sample | 9 | Houses/Greenhouses | Lengel, J.D., bldr. | Note: Includes various sketches and working drawings for Marco house (n.d), Cahall house (1936), F.C. Leas boiler room (n.d.), greenhouse (1936), John T. Troth house (1937), and Mrs. MacCoy Malloy house, Devon, Pa., (1937). | 1936-1937 | ||||
| PEW.RHS.1.39 | 1 | [Small residence.] | Smith, Walter B., dev. | Smith #83 | ||||||
| PEW.RHS.1.40 | Sample 1 |
11 | Houses | Boyd, D. Knickerbacker | Smith, Walter B., dev. | Architect's job nos. 403, 420, 483, 485, 482, 489, 490, 486, and 484. Includes rendered perspectives, elevations, and floor plans for suburban house plans. | 1902-1904 | |||
| PEW.RHS.1.41 | Sample | 4 | House "A" | Price, Frank L. and William L. | Wendell and Smith | 308, 328, 408, 415 Midland Avenue, 210, 226 Windermere Ave., Wayne PA 19087 | Smith #82 | 1890 | ||
| PEW.RHS.1.42 | Sample | 1 | House | DeNean, D. Judge | Smith, Walter B., dev. | 37 and 39 St. Pauls Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | 1902 | ||
| PEW.RHS.1.43 | 1 | House (Plan no. 2) | DeNean, D. Judge | Smith, Walter B., dev. | Dallas, client | 23 and 27 Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #14 | 1899 | |
| PEW.RHS.1.44 | Sample | 2 | House | DeNean, D. Judge | Smith, Walter B., dev. | Brock, client | 19 and 27 Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #13 | 1898 |
| PEW.RHS.1.45 | Sample | 2 | House no. 10 | DeNean, D. Judge | Smith, Walter B., dev. | Wainwright, client | 16 Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #11 | 1910 |
| PEW.RHS.1.46 | Sample | 2 | House no. 11 | DeNean, D. Judge | Smith, Walter B., dev. | Litch and Cresson, clients | 14 and 22 Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #10 | 1910 |
| PEW.RHS.1.47 | Sample | 4 | House no. 9 | DeNean, D. Judge | Smith, Walter B., dev. | Coffin, client | 21 Linwood Ave., Ardmore, Pa. |
Ardmore (W.B. Smith) | Smith #8 | 1910 |
| PEW.RHS.1.48 | 1 | Parsonage | Price, William L. | Smith, Walter B., dev. | St. Paul's Evangelical Lutheran Church | Lancaster Ave., Ardmore, Pa. | Ardmore (W.B. Smith) | |||
| PEW.RHS.1.49 | Sample | 1 | House no. 2 (4 house operation) | Dagit Brothers | Smith, Walter B., dev. | Wynnewood, Pa. | 1924 | |||
| PEW.RHS.1.50 | Sample | 5 | House no. 5 | DeNean, D. Judge | Smith, Walter B., dev. | Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #2 | 1903-1907 | |
| PEW.RHS.1.51 | Sample | 3 | House | Boyd, Abel, and Gugert | Smith, Walter B., dev. | Hansell Rd. and Millers Ln., Wynnewood, Pa | Wynnewood Manor | Smith #3; Architect's work no. 1318. | 1924 | |
| PEW.RHS.1.52 | Sample | 4 | Apartment House (Alts & Add.) | Trumbauer, Horace | Smith, Walter B., dev. | 116 and 118 Argyle Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #4 and #23 | 1916 | |
| PEW.RHS.1.53 | Sample | 2 | House no. 1 | DeNean, D. Judge | Smith, Walter B., dev. | 7 and 27 St. Pauls Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #17 | 1903 | |
| PEW.RHS.1.54 | Sample | 3 | House no. 4 | DeNean, D. Judge | Smith, Walter B., dev. | 16 and 20 St. Pauls Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #16 | 1903 | |
| PEW.RHS.1.55 | Sample | 6 | House (Alt. and add.) | Pollock, Robert W. | Smith, Walter B., dev. | 116 Argyle Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #24 | 1917 | |
| PEW.RHS.1.56 | Sample | 1 | House No. 420 | Boyd, D. Knickerbacker | Smith, Walter B., dev. | Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #31 | 1902 | |
| PEW.RHS.1.57 | Sample | 1 | House | Heacock and Hokanson | Smith, Walter B., dev. | Eyebrow, Saskatchewan, Canada | Note: This structure is a small hut or sporting cabin with three rooms. | Smith #63 | 1910 | |
| PEW.RHS.1.58 | Sample | 1 | House | Watson and Huckel | Smith, Walter B., dev. | 45 Manor Rd., Wynnewood, Pa. | Wynnewood Manor | Smith #40 | 1905 | |
| PEW.RHS.1.59 | Sample | 6 | House | Heacock and Hokanson | Smith, Walter B., dev. | 38 Manor Rd., Wynnewood, Pa. | Wynnewood Manor | Smith #39 | 1908-1920 | |
| PEW.RHS.1.60 | Sample | 1 | Stores | Heacock and Hokanson | Smith, Walter B., dev. | Montgomery Ave. and Mill Rd., Wynnewood, Pa. | Wynnewood Manor | Architect's job no. 593. | 1927 | |
| PEW.RHS.1.61 | Sample | 8 | House | Lengel, J.D., bldr. | Rough sketches and rough final drawings with drawings on verso. | 1920 | ||||
| PEW.RHS.1.62 | Sample | 1 | Bungalow | Boyd, Abel, and Gugert | Walton, client | 1920 | ||||
| PEW.RHS.1.63 | Sample | 2 | House | Quillman, E., del. | Lengel, J.L., client | 1924 | ||||
| PEW.RHS.1.64 | Sample | 1 | House | Lengel, J.D., bldr. | Lengel, Johnathan M., client | Lenoir Ave., Wayne, Pa. | 1919 | |||
| PEW.RHS.1.65 | Sample | 2 | House | Lengel, J.D., bldr. | 1900 | |||||
| PEW.RHS.1.66 | Sample | 11 | House | Gugert, Francis A. | Lengel, J.D., bldr. | Wayne, Pa. | 248-250 Conestoga Road, Wayne PA 19087 | Architect's job no. 35055. | 1897 | |
| PEW.RHS.1.67 | Sample | 10 | House (Heating plan) | Lengel, J.M., del. | Lengel, J.D., dev. | Berwyn, Pa. | Architect's work no. 30A. | 1936 | ||
| PEW.RHS.1.68 | Sample | 3 | House | Boyd, Abel and Gugert | Lengel, J.D., dev. | 1922 | ||||
| PEW.RHS.1.69 | Sample | 8 | House | Lengel, J.M., del. | Lengel, J.D., dev. | Berwyn, Pa. | Architect's work no. 30. | 1936 | ||
| PEW.RHS.1.70 | Sample | 1 | House no. 2 | Trumbauer, Horace | Smith, Walter B., dev. | Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #1; Architects job no. 1728. | 1899 | |
| PEW.RHS.1.71 | Sample | 1 | House | Trumbauer, Horace | Smith, Walter B., dev. | 33 and 36 Manor Rd., Wynnewood, Pa. | Wynnewood Manor | Smith #38 | 1910 | |
| PEW.RHS.1.72 | Sample | 1 | Garage | Boyd, Abel and Gugert | O. Howard Wolfe | Radnor, Pa. | 1919 | |||
| PEW.RHS.1.73 | Sample | 1 | Roberts Road Bridge | Yerkes, Milton R. eng | Radnor, Pa. | 1926 | ||||
| PEW.RHS.1.74 | Sample 1 Sample 2 |
2 | Residences for Rosemont Improvement Co. | Gugert, Francis A. | Rosemont, VA. | 1909 | ||||
| PEW.RHS.1.75 | Sample | 1 | Garage | Rush, Louis H. | Dr. G.L.S. Jameson | St. Davids, Pa. | 1916 | |||
| PEW.RHS.1.76 | Sample | 3 | Alterations to House | DeArmond, Ashmead, and Bickley | 218 Lancaster Ave., Wayne, Pa. | 1945 | ||||
| PEW.RHS.1.77 | Sample | 2 | Jamesway poultry house | James Manufacturing Co. Ft. Atkinson, WI |
1923-24 | |||||
| PEW.RHS.1.78 | Sample | 5 | Residence | Street, J. Fletcher | Mr. Charles Bayliss | 210 Pembroke Ave., Wayne, Pa. | 1926 | |||
| PEW.RHS.1.79 | Sample | 1 | House | Boyd, Abel, and Gugert | Wm. D. Smedley | 19 Woodbine Ave., Narberth, Pa.; 20 Avon Rd., Narberth, Pa.; 45 Louella Court, Wayne, Pa. | Architect's work no. 1080. | 1919 | ||
| PEW.RHS.1.80 | Sample | 1 | Masonry milk house; W.L. Hirst barn no. 2. | Weadon, P.A., Jr., eng. | R.H. Johnson Co. | Wayne, Pa. | ||||
| PEW.RHS.1.81 | Sample | 1 | Garden house and tool shed, Henry F. Perot | Weadon, P.A., Jr., eng. | R.H. Johnson Co. | Rosemont, Pa. | ||||
| PEW.RHS.1.82 | Sample | 1 | Residence | Mr. Wood | Wayne, Pa. | |||||
| PEW.RHS.1.83 | Sample | 1 | Two-Story Dwelling | Sinclair, Norman P. | 120 Bellevue Avenue, Wayne PA 19087 | Architect's job no. 197. | 1914 | |||
| PEW.RHS.1.84 | Sample | 17 | Residence | Trane Co., (LaCrosse, WI) | Powell Construction Co. | Canizares, Arlington W. | 782 Harrison Road, Villanova PA 19085 | 1930 | ||
| PEW.RHS.1.85 | Sample | 2 | [Residence] | Gugert, Francis A. | Canizares, J. | Wayne, Pa. | 1911 | |||
| PEW.RHS.1.86 | Sample | 1 | Alterations to residence of Mr. R.S. McKinley | White, Ralph E. | McKinley, Mr. R.S. | Wayne, Pa. | ||||
| PEW.RHS.1.87 | Sample | 4 | Swimming pool and garden | Willing, Sims, and Talbutt | Wainwright, Mrs. T.D. | Gwynedd, Pa. | 1931 | |||
| PEW.RHS.1.88 | Sample | 1 | Bridge | Cridland, Robert B., lands. archt. | Philler, W.W. | Wynnewood, Pa. | 1927 | |||
| PEW.RHS.1.89 | Sample | 2 | Garden house | Tilden, Register, and Pepper | Robinson Flagstone Co. | Thompson, Mrs. Frank | Valley Forge, Pa. | 1930 | ||
| PEW.RHS.1.90 | Sample | 3 | Garage | Boyd, Coneys, and Abel | Lengel, J.D., bldr. | Savidge, Frank R. | Devon, Pa. | 1914 | ||
| PEW.RHS.1.91 | Sample | 7 | Bungalow | Lengel, J.D., bldr. | Davis, Mr. & Mrs. Paul J. | Berwyn, Pa. | 1935 | |||
| PEW.RHS.1.92 | Sample | 3 | Residence | DeArmond, Ashmead, and Bickley |
Booth, H.D., Jr. | St. Davids, Pa. | 1946 | |||
| PEW.RHS.1.93 | Sample 1 Sample 2 Sample 3 Sample 4 Sample 5 |
7 | Development of Willow Burn Farm [residences] | Rush, Louis H. | Lengel, J.D., bldr. | Chew Family Commercial Trust Co. | 102, 103, 104, 106, 113 Quaker Lane, Villanova PA 19085 | Willow Burn Farm | 1922-1924 | |
| PEW.RHS.1.94 | 3 | Residence, Alts. | Webb, A. J. | Aman, Mr. and Mrs. George | 425 Darby-Paoli Road, Wayne PA 19087 | 1919 | ||||
| PEW.RHS.1.95 | Sample | 3 | House | DeNean, D. Judge | Smith, Walter B., dev. | Blackall, C.R. | 25 St. Pauls Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | ||
| PEW.RHS.1.96 | 4 | Lengel, J.D., bldr. | Wayne Building and Loan Association | Wayne, Pa. | Colonial Village | 1934 | ||||
| PEW.RHS.1.97 | Sample | 3 | Bridge | Delano and Aldrich, archts.; Vitale, Ferrucio, lands. archt. |
Rhoads, Charles J. | Bryn Mawr, Pa. | 1927 | |||
| PEW.RHS.1.98 | 1 | Conversion to an apartment in the Spread Eagle Inn | DeArmond, Ashmead and Bickley | Diament, Francis H. | Lancaster Pike, Strafford, Pa. | 1942-1943 | ||||
| PEW.RHS.1.99 | Sample | 1 | Residence | Shaw, J. William | Strait, Charles W.T. | North Wayne Ave. Wayne, Pa. |
1927 | |||
| PEW.RHS.1.100 | Sample | 3 | Proposed garage | Pollock, Robert W. | Smith, Alan G., bldr.; Smith, Walter B., dev. |
Peddle, George C. | 203 North 63rd St., Overbrook, Philadelphia, Pa. | 1917 | ||
| PEW.RHS.1.101 | Sample | 1 | Garage | Street, J. Fletcher | Lewis, Mr. Paul L. | Strafford, Pa. | 1929 | |||
| PEW.RHS.1.102 | Sample | 3 | House | Heacock and Hokanson | Smith, Walter B., dev. | Musser, W.B. | 17 Simpson Rd., Ardmore, Pa. | Ardmore (W.B. Smith) | 1903-1904 | |
| PEW.RHS.1.103 | Sample | 3 | Sketch of a parish house, All Saints Church | Price, Walter F. | Wynnewood, Pa. | Wynnewood Manor | Smith #43 | 1916 | ||
| PEW.RHS.1.104 | Sample | 11 | Residence (Alts & Adds.) | Willing, Sims & Talbutt | Pepper, Dr. O.H. | 939 Parkes Run Lane, Villanova PA 19085 | 1928 | |||
| PEW.RHS.1.105 | Sample | 3 | Post Office, Devon Station, proposed addition | Cookman, William H., Pennsylvania Railroad Company | Devon, Pa. | 1925 | ||||
| PEW.RHS.1.106 | 3 | Union Hall, Additions | J. William Shaw | Wayne, Pa. | 1892 | |||||
| PEW.RHS.1.107 | Sample | 14 | Masonic Hall, Lodge #581 | Gugert, Francis A. | Wayne, Pa. | 1915 | ||||
| PEW.RHS.1.108 | 2 | Dining Room Adds. | Edwards & Hoffman | Finley, Charles | 324 Midland Ave., Wayne, Pa. | 1936 | ||||
| PEW.RHS.1.109 | Sample | 19 | Building and garage | Smedley, Walter | Brookmead Guernsey Dairies | Lancaster Avenue Wayne, Pa. |
1923-1929 | |||
| PEW.RHS.1.110 | Sample | 1 | Emergency Exit for lunch room, Grade School, Tredyffrin Township, PA | Edwards, E. Nelson | 1937 | |||||
| PEW.RHS.1.111 | Sample 1 Sample 2 Sample 3 Sample 4 Sample 5 Sample 6 Sample 7 Sample 8 |
9 | Houses #1-8 | Frank Seeburger & Charles Rabenold |
James R. Scott & A.W. Supplee | Merion, Pa. | ||||
| PEW.RHS.1.112 | Sample | 2 | Apartment House | 63rd St., Overbrook, Philadelphia, PA | 1916 | |||||
| PEW.RHS.1.113 | Sample | 1 | House | Price, William L. | Sweeney, F.D. | 6346 Sherwood Rd., Overbrook, Philadelphia, PA | Smith #111 | |||
| PEW.RHS.1.114 | Sample | 2 | House | DeNean, D. Judge | Smith, Walter B., dev. | Jones, Mrs. Anna C. | Ardmore, Pa. | Ardmore (W.B. Smith) | 1900 | |
| PEW.RHS.1.115 | Sample | 6 | Chicken House and Tool Room | Lengel, J.D., bldr. | Colket, Percy G. | ca. 1912 | ||||
| PEW.RHS.1.116 | Sample | 15 | Alterations and Additions, Residence | Huston, Joseph M. and Stanford B. Lewis | Dale, Leroy E. | 421 Woodland Avenue, Wayne PA 19087 | Work #1011 | 1929 | ||
| PEW.RHS.1.117 | Sample | 2 | Storage Shed | Lengel, J.D., bldr. | Wayne Iron Works | Wayne, Pa. | 1928 | |||
| PEW.RHS.1.118 | Sample | 4 | Garage & Storage Shed | Lengel, J.D., bldr. | Valley Forge Chemical Company | King of Prussia, Pa. | 1934 | |||
| PEW.RHS.1.119 | Sample | 7 | DeArmond, Ashmead & Bickley | Residence | Conn, Charles F. | 417 St. Davids Road, Wayne PA 19087 | 1921-1922 | |||
| PEW.RHS.1.120 | 5 | Convalescent Hospital and Home | Lengel, J.D., bldr. | Broomall, Pa. | 1928 | |||||
| PEW.RHS.1.121 | Sample | 3 | Cottage | Boyd & Abel | Kendrick, George W. | 560 Sproul Road, Villanova PA 19085 | Work #1044 | 1919 | ||
| PEW.RHS.1.122 | Sample | 1 | Garden House | Newbold, F.E. | Devon, Pa. | |||||
| PEW.RHS.1.123 | Sample | 2 | Residence | DeNean, D. Judge | Smith, Walter B., dev. | DeNean, D. Judge | Ardmore, Pa. | Ardmore (W.B. Smith) | Smith #7 | |
| PEW.RHS.1.124 | Sample | 1 | Construction details | Sears, Thomas W., lands. arch. | Audenried, Mrs. Lewis | Newtown Township, Delaware County, Pa. | 1929 | |||
| PEW.RHS.1.125 | Sample | 7 | Alterations to parish house and new rectory | Zantzinger, Borie & Medary | St. Mary's P.E. Church | 103 Louella Avenue, Wayne PA 19087 | 1930 | |||
| PEW.RHS.1.126 | Sample | 7 | Post office building, Villa Nova Station | Cookman, William H., Pennsylvania Railroad Company | Villa Nova, Pa. | 1926-1930 | ||||
| PEW.RHS.1.127 | Sample | 1 | Garage | Lengel, J.D., bldr. | Conestoga Inn | Strafford, Pa. | 1937 | |||
| PEW.RHS.1.128 | Sample | 1 | Extension to Merion station and post office. | Lengel, J.D., bldr. | Pennsylvania Railroad, Eastern Division | Merion, Pa. | 1917-1926 | |||
| PEW.RHS.1.129 | Sample | 3 | Details for house for Isaac Clothier, Jr. | Karcher and Smith | Clothier, Isaac H., Jr. | Radnor, Pa. | 1926 | |||
| PEW.RHS.1.130 | Sample | 2 | [Chicken house] | Clothier, Isaac H., Jr. | Radnor, Pa. | 1926-1927 | ||||
| PEW.RHS.1.131 | Sample | 1 | Details for reconstruction at old barn | Sears, Thomas W., lands. archt. | Clothier, Isaac H., Jr. | Radnor, Pa. | 1926 | |||
| PEW.RHS.1.132 | Sample | 2 | Add. to tenant house | Karcher and Smith | Clothier, Isaac H., Jr. | Radnor, Pa. | 1928 | |||
| PEW.RHS.1.133 | Sample | 1 | Shelter at pond | Paul, Paul, and Ford | Clothier, Isaac H., Jr. | Radnor, Pa. | 1916 | |||
| PEW.RHS.1.134 | Sample | 3 | Tenant house | Karcher and Smith | Lengel, J.D., bldr. | Clothier, Isaac H., Jr. | Radnor, Pa. | 1926 | ||
| PEW.RHS.1.135 | Sample | 5 | Ice making plant | Greene, Van R. H. | Bryn Mawr Ice Co. | 229 Willow Avenue, Wayne PA 19087 | 1924-1925 | |||
| PEW.RHS.1.136 | Sample 1 Sample 2 |
6 | Alt. and add. to house for Mr. Roger Warner | Wallace and Warner | Warner, Roger | 507 Woodland Court, Wayne PA 19087 | 1922-1930 | |||
| PEW.RHS.1.137 | Sample | 4 | House to be built at Wayne, Penna. for Mr. C.H. Wetzel | Boyd, Abel, and Gugert | Wetzel, C.H. | 214 South Wayne Avenue, Wayne PA 19087 | 1919 | |||
| PEW.RHS.1.138 | Sample | 3 | Alt. for [residence of] C.H. Wetzel |
Wetzel, C.H. | 214 South Wayne Avenue, Wayne PA 19087 | 1929 | ||||
| PEW.RHS.1.139 | Sample | 3 | [Residence Louella.] dwelling new construction | Boyd, Abel, and Gugert | 15 Louella Court, Wayne PA 19087 | |||||
| PEW.RHS.1.140 | Sample | 3 | Alt. to the house of Miss E.R. Harrar. | Rush, Louis H. | Harrar, E.R., Miss | Devon, Pa. | 1925 | |||
| PEW.RHS.1.141 | Sample | 2 | Suburban residence for Alan G. Smith, Esq. | Pollock, Robert W. | Smith, Alan G., dev. | 1916 | ||||
| PEW.RHS.1.142 | Sample | 1 | Suburban residence at Narberth, Penna. for Alan G. Smith | [Boyd, D. Knickerbacker] | Smith, Alan G., dev. | Meeting Ave. (East), 20, Narberth Pa. | ||||
| PEW.RHS.1.143 | Sample | 9 | Garage for 2035 N. 63rd Street, Overbrook | Smith, Alan G., dev. | N. 63rd Street, Overbrook, Philadelphia, Pa. | 1921 | ||||
| PEW.RHS.1.144 | Sample | 2 | [Residence] | Boyd, Coneys, and Abel | 1914 | |||||
| PEW.RHS.1.145 | Sample | 1 | House no. 106A | Boyd, D. Knickerbacker | Lengel, J.D., bldr. | 1905 | ||||
| PEW.RHS.1.146 | Sample | 1 | Unidentified Residence | Boyd, D. Knickerbacker | 220 Lenoir Avenue, Wayne PA 19087 | Work #858 | ||||
| PEW.RHS.1.147 | Sample | 1 | House #103 | Boyd, D. Knickerbacker | 225 Lenoir Avenue, Wayne PA 19087 | Work #570 | 1905 | |||
| PEW.RHS.1.148 | Sample | 1 | Boyd, D. Knickerbacker | Hale, Ira V. | Wayne, Pa. | Work #912 | 1915 | |||
| PEW.RHS.1.149 | Sample | 1 | Small house at Hammond and Brockhurst Avenue | Boyd, D. Knickerbacker | Narberth, Pa. | Work #659 | 1906 | |||
| PEW.RHS.1.150 | Sample | 1 | Residence #334 | Gugert, Francis A. | ||||||
| PEW.RHS.1.151 | Sample | 1 | House for Frank R. Mahon | McIlvain and Roberts | Ardmore, Pa. | 1908 | ||||
| PEW.RHS.1.152 | Sample | 1 | Small house | Trumbauer, Horace | Smith, Walter B., dev. | 1912 | ||||
| PEW.RHS.1.153 | Sample | 7 | L.H. Watt Residence | Watt, L.H. | ||||||
| PEW.RHS.1.154 | Sample | 4 | House #30 | Boyd, Abel & Gugert | Smith, Walter B., dev. | Wynnewood, Pa.; 15 Fariston Road, Wayne PA 19087 | 1919 | |||
| PEW.RHS.1.155 | Sample | 3 | House | Parker, Charles S. | Smith, Alan G., dev. | 27 E. Athens Ave., Ardmore, Pa. | 1923 | |||
| PEW.RHS.1.156 | Sample | 2 | Residence of Fred L. Harding | Parker, Charles S. | Smith, Alan G., dev. | Harding, Fred L. | 50 Manor Rd., Wynnewood, Pa. | Wynnewood Manor | 1927 | |
| PEW.RHS.1.157 | Sample | 6 | Boilers, Heating Plant, Septic System for Wynnewood Manor | Pugh & Hubbard; Heacock & Hokanson; W.A. Drysdale | Smith, Walter B., dev. | Wynnewood, Pa. | Wynnewood Manor | 1906 | ||
| PEW.RHS.1.158 | Sample | 6 | Alterations and additions to residence | Edwards, E. Nelson | Ellis, Thomas S. | Near West Chester, Pa. | 1940 | |||
| PEW.RHS.1.159 | Sample | 37 | Apartment house | Boyd, Abel & Gugert | Bard, Mr. and Mrs. J. Frazier | 223 Bloomingdale Avenue, Wayne PA 19087 | Work #1533 | 1928 | ||
| PEW.RHS.1.160 | Sample | 14 | Wall and ramps for garden | Cuppy, Robert Overton, designer | Lengel, J.D., bldr. | Jacobs, John | Highland Ln., & Coopertown Rd., Bryn Mawr, Pa. | 1927 | ||
| PEW.RHS.1.161 | Sample | 2 | House #3 at Merion, PA | Boyd, Abel & Gugert | Walter Paschall & Son, dev. | Merion, Pa. | Work #1233 | 1922 | ||
| PEW.RHS.1.162 | Sample | 43 | Residence | Adams, Alexander Mackie | Lengel, J.D., bldr. | Jacoby, John F., Jr | Woodbine Avenue above Montgomery Avenue, Lower Merion, Pa. | 1926-1927 | ||
| PEW.RHS.1.163 | Sample | 26 | Residence | Stout, Penrose V. | Mothern, Emil H. | Wayne, Pa. | 1928 | |||
| PEW.RHS.1.164 | Sample | 1 | One story bungalow, Ivorcroft Farm | Keast, W.R. Morton | Jefferson Hospital | 1939-1940 | ||||
| PEW.RHS.1.165 | Sample | 8 | Alterations and additions to residence | Rush, Louis H. and Bissell and Sinkler | Hare, T. Truxton | Radnor, Pa. | 1927 | |||
| PEW.RHS.1.166 | Sample | 4 | T. Leaming Smith residence | Adams, Alexander Mackie | Woodbine Avenue, Lower Merion, Pa. | 1927-1929 | ||||
| PEW.RHS.1.167 | 3 | Renovations to residence for Charles S. Walton | Wadsworth, Reginald J. | Lengel, J.D., bldr. | Walton, Charles S. | St. Davids, Pa. | 1932 | |||
| PEW.RHS.1.168 | Sample | 5 | Residence for J.P. Lengel, Phoenixville, Pa. | Wadsworth, Reginald J. | Lengel, J.D., bldr. | 1927 | ||||
| PEW.RHS.1.169 | Sample | 11 | Alterations and additions to house for George S. Munson | Willing, Sims & Talbutt | Munson, George S. | Overbrook, Philadelphia, Pa. | includes drawing for service wing by Furness, Evans & Co., 1916 | 1923-1925 | ||
| PEW.RHS.1.170 | Sample | 12 | Store and apartment building for George L. Harrison | Mackenzie & Wiley | 124 East Lancaster Avenue, Wayne PA 19087 | 1928 | ||||
| PEW.RHS.1.171 | Sample | 2 | Second Story Porch for Walter B. Smith, Esq. | Smith, Alan G., bldr. | 6490 Woodbine Ave., Overbrook, Philadelphia, Pa. | 1921 | ||||
| PEW.RHS.1.172 | 1 | Detail of Bookcase for J.D. Lengel | Wadsworth, Reginald J. | Lengel, J.D., bldr. | Wayne, Pa. | 1931 | ||||
| RHS.1.173 | Sample | 5 | Plans of House and Stable for Wm. Wood Esq. to be Erected at Wayne, Pa. | Hazlehurst and Huckel | Wood, William | 30 & 34 West Avenue, Wayne PA 19087 | 1897 | |||
| RHS.1.174 | Sample | 4 | House no. 36, Cynwyd, Pa. | Seeburger, Frank | Cynwyd, Pa. | Smith #96 | 1921 | |||
| RHS.1.175 | 1 | Plans for 2-story House | Price, Walter F. | Smith #78 | 1918 | |||||
| RHS.1.176 | Sample | 4 | House at Narbrook, Narberth Penna. On Property No. 9 for James Artman Esq. | Boyd, D. Knickerbacker | Artman, James Esq. | Narbrook Park, Narberth, Pa. | Work #929; Smith #97 | 1915 | ||
| RHS.1.177 | 1 | Houses on Montgomery Ave., Narberth | Narberth, Pa. | Smith #107 | ||||||
| RHS.1.178 | Sample | 25 | Residence for Mr. & Mrs. H.A. Winters, Radnor, Penna. | Duhring, H. Louis | Winters, Mr. & Mrs. H.A. | 324 Orchard Way, Wayne PA 19087 | 1937 | |||
| RHS.1.179 | Sample | 8 | Dwelling for Mr. William H. Palmer, Wayne, Pa. | Piombino, Samuel J. | 310 Orchard Way, Wayne, PA 19087 | |||||
| RHS.1.180 | Sample | 8 | The Wayne Title & Trust Company | Mackenzie & Wiley | The Wayne Title & Trust Company | 100 West Lancaster Avenue, Wayne PA 19087 | Work #2909 | 1929 | ||
| RHS.1.181 | Sample | 10 | House for W. Hinckle Smith, Esq. | Platt, Charles A. | Bryn Mawr, Pa. | Work #259 | 1907 | |||
| RHS.1.182 | Sample | 8 | Alterations & Additions to the Radnor Fire House | Gugert, Francis A. | Radnor Fire Co. | 121 South Wayne Avenue, Wayne PA 19087 | Work #1657 | 1935 | ||
| RHS.1.183 | Sample | 1 | Residence for P.C. Colket, Esq. | McIlvain and Roberts | 115 Strafford Avenue, Wayne PA 19087 | Work #243 | 1909 | |||
| RHS.1.184 | Sample | 3 | Residence for Ira V. Hale, Esq. | Boyd, D. Knickerbacker | Hale, Ira V. | Wayne, Pa. | Work #853 | 1912 | ||
| RHS.1.185 | Sample | 6 | Tile and Stucco House - House No. 1 - Lot No. 1 | Boyd, Abel & Gugert | Lengel, J.D., bldr. | Lengel, J.D. | 307 Banbury Way, Wayne, PA 19087 | Work #1391 | 1925 | |
| RHS.1.186 | Sample | 8 | Clapboard Frame House - House No. 2 - Lot No. 3 | Boyd, Abel & Gugert | Lengel, J.D., bldr. | Lengel, J.D. | 315 Banbury Way, Wayne, PA 19087 | Work #1392 | 1925 | |
| RHS.1.187 | Sample | 8 | Stucco & Hollow Tile House - House No. 3 - Lot No. 5 | Boyd, Abel & Gugert | Lengel, J.D., bldr. | Lengel, J.D. | 323 Banbury Way, Wayne, PA 19087 | Work #1393 | 1925 | |
| RHS.1.188 | Sample | 3 | Residence at St. Davids, Pa. | Roberts, Chas. H. | Schroeder, Mr. Seaton | Work #751 | 1952 | |||
| RHS.1.189 | 1 | Proposed Treatment of Entrance at "Fox Hill," Bryn Mawr for Rudolf Ellis, Esq. | Eyre, Wilson | Ellis, Rudolf, Esq. | 548 Bryn Mawr Avenue, Bryn Mawr PA 19010 | 1911 | ||||
| RHS.1.190 | Sample | 6 | Cottage at Wayne, Pa for Messers. Wendell and Smith | Worthington, J.C. | Wendell & Smith | Wendell & Smith | 412 Chestnut Ln., 400, 405, 409, 413, 417 Oak Ln., 103, 125, 210 Walnut Ln., 405, 407, 409 N. Wayne Ave., 406, 410, 418 Woodland Ave., Wayne, Pa. |
Wayne | 1887 | |
| RHS.1.191 | ||||||||||
| PEW.RHS.2.1 | Sample | 1 | Plan of Proposed Penn Lane at Wynnewood, Penna | Rogers, Alva L., R.L.S. | W. Gordon Smith, Agent | Penn Lane between Penn Road and Wynnewood Road, Wynnewood, Pa. | Wynnewood Manor | |||
| PEW.RHS.2.2 | Sample | 1 | Map of Property Situate at Wayne, Penna., Intersection of West Wayne Avenue and Bloomingdale Avenue | Yerkes, Milton R, C.E. | Wayne, Pa. | Jan. 1923 | ||||
| PEW.RHS.2.3 | Sample | 1 | Property surrounding Wynnewood Manor, also "Olinda" 31.152 acres for sale | McDowell, A.P. | Wynnewood, Pa. | Wynnewood Manor | On verso: "McDowell Tract Wyn. Manor". Smith #54, Other key names included on the map: Magee, Winsor, Hopper, Perot, Morris, M.C. Smith | |||
| PEW.RHS.2.4 | Sample | 1 | Residential Building Sites [for sale by] Girard Trust Company "Austin Tract, Rosemont, Lower Merion Township, Montgomery Co." | Gulph Road & Roberts Road | 1948 | |||||
| PEW.RHS.2.5 | Sample | 2 | "Survey of Ground under bridge at Overbrook Station" | Johnson, Joseph, Surveyor | City Avenue at Drexel Road, Overbrook, Philadelphia, Pa. | Mar. 1917 | ||||
| PEW.RHS.2.6 | Sample | 5 | [Plans of Narberth]; "Property of Walter B. Smith, Esq." | Yerkes, Milton R., J.P.P. Lathrop & Robbey A. Warner | Montgomery Avenue, Narberth, Pa. | 1906-1919 | ||||
| PEW.RHS.2.7 | Sample | 1 | "Willow Burn Radnor, PA Preliminary Plan" | Adams, Louis A., landscape architect | Estate of David S. B. Chew, Benjamin Chew, Oswald Chew, Commercial Trust Company | Radnor, Pa. | ||||
| PEW.RHS.2.8 | Sample | 2 | "Map of Ground Adjacent to Willowburn Station P & W Rwy. Co. Radnor Twp., Delaware Co., Pennsylvania" | Yerkes, Milton R., C.E. | Quaker Lane and Hillside Circle | Willow Burn | Key names on the map include: Simons, Alexander, Chew Estate | May, 1938 | ||
| PEW.RHS.2.9 | Sample | 1 | [Site Plan of Lots - Ardmore] | Linwood Ave. at Lancaster Ave. | Ardmore (W.B. Smith) | Smith #30 | ca. 1898 | |||
| PEW.RHS.2.10 | Sample | 2 | "Plan of lots at Ardmore - Walter Bassett Smith" | Lathrop, John P., C.E. | St. Pauls Road, Simpson Road, Athens Avenue, Linwood Avenue | Ardmore (W.B. Smith) | Assessment map of 1907, Shows all lots with owners and prices. | 1907 | ||
| PEW.RHS.2.11 | Sample | 2 | "Plan of Wynmere Road at Wynnewood, Penna" | Rogers, Alva L., R.L.S., W. Gordon Smith | Key names include Minnick, Goodman, Jones | Jan. 1928 | ||||
| PEW.RHS.2.12 | Sample | 1 | "Map of Property about to be conveyed by Henry R. Shock, Lower Merion Twp. Montg. Co. Pa." | Yerkes, Milton R., C.E. | Wynnewood Ave. at Montgomery Ave. | Smith #53; Key names include W.L. McDowell, Norris Hansell | Jan. 1905 | |||
| PEW.RHS.2.13 | Sample | 1 | "Plan of Building Lots, The Property of Walter B. Smith situate at Ardmore, Pennsylvania" | Garrigues, Samuel, C.E. | Smith, Walter B., dev. | Between Athens Ave. & Lancaster Ave. | Ardmore (W.B. Smith) | Smith #29; Key names include: Becker, Kugler, St. Paul's Lutheran Church, Ardmore Real Estate Association |
Jun. 1895 | |
| PEW.RHS.2.14 | Sample | 1 | Plan of Bldg. lots [for] the property of Walter B. Smith | Garrigues, Samuel M., C.E. | Smith, Walter B., dev. | Lancaster Ave., Ardmore, Pa. | Ardmore (W.B. Smith) | |||
| PEW.RHS.2.15 | Sample | 1 | Plan of building lots[for] the property of Walter B. Smith | Garrigues, Samuel M., C.E. | Smith, Walter B., dev. | Athens/Linwood Aves. Ardmore, Pa. | Ardmore (W.B. Smith) | Other key names included on this map: Kugler, St. Paul's Lutheran Church, Simpson Memorial, M.E. Church, Kecker, Dickerson Bros., and Hicks | ||
| PEW.RHS.2.16 | Sample | 2 | Plan of W.B. Smith lots, Ardmore | Athens/Lancaster Aves. Simpson Ave., Ardmore, Pa. | Ardmore (W.B. Smith) | Other key names included on this map: Alan G. Smith, Bevan, Reinhard, Balderston, Ycett, Spaulding, St. Coleman's Roman Catholic Church, Simpson Memorial and M.E. Church | ||||
| PEW.RHS.2.17 | Sample | 1 | Plan of Pelham, Wendell and Smith, Managers | Wendell & Smith | Germantown, Philadelphia, Pa. | 1907 | ||||
| PEW.RHS.2.18 | Sample | 1 | Overbrook Farms, Wendell and Smith, Mgs. | Wendell & Smith | 66th to 58th Street City/Woodbine Aves., Overbrook, Philadelphia, Pa. | |||||
| PEW.RHS.2.19 | Sample 1 Sample 2 |
4 | Plan north side of 63rd street, Overbrook | Overbrook, Philadelphia, Pa. | 1920 | |||||
| PEW.RHS.2.20 | Sample | 2 | Map of the estate of Norris Hansell, dec'd., situated in Lower Merion twp | Yerkes, Milton K., C.E. | Montgomery Ave., McClenachan Mill Rd. | Wynnewood Manor | Other key names mentioned on this map: Henry R. Shoch, William L. McDowell and J.& M. Magee | 1902 | ||
| PEW.RHS.2.21 | Sample | 2 | [Property Plans for Chester County] Easttown and Whiteland twps. Chester PA property map community plan | Yerkes, Milton R., Yerkes Engineering Company | Includes the following estates: Alfred Lohmann (1929) and Martin Spinelli (1957). | |||||
| PEW.RHS.2.22 | Sample | 2 | Plan showing old and new streets in the vicinity of Overbrook Station | Philadelphia, Pa. | 1930 | |||||
| PEW.RHS.2.23 | Sample | 12 | [Maps of Willow Burn] | Yerkes, J.B., C.E. Yerkes, M.R., C.E. | Radnor, Pa. | 1927-1954 | ||||
| PEW.RHS.2.24 | Sample | 4 | Overbrook Farms, a modern suburban home place on the... Main Line | Wendell & Smith | 66th to 57th Streets City to Woodbine Aves. Overbrook, Philadelphia, Pa. | 1899-1917 | ||||
| PEW.RHS.2.25 | Sample | 1 | [Plan of Walter B. Smith lots, Ardmore] | Athens/Lancaster Aves. St.Pauls/Simpson Rds., Ardmore, Pa. | Ardmore (W.B. Smith) | |||||
| PEW.RHS.2.26 | Sample | 1 | Preliminary plan scheme for the development of land at Wynnewood | Wendell, Herman, lands. arch. Wendell, E.J. del. | Montgomery Ave., Wynnewood, Pa. | Wynnewood Manor | 1907 | |||
| PEW.RHS.2.27 | Sample | 8 | [List and plat of property owners in Devon, Pa.] | Brown, C.P. | Devon Citizen Association | Devon, Pa. | 1930 | |||
| PEW.RHS.2.28 | Sample | 1 | Plan no. 1 road plan of Lower Merion Township | Allbright, Chester E., C.E. | Lower Merion Township, Pa. | 1903 | ||||
| PEW.RHS.2.29 | Sample | 1 | General plan suggesting subdivision of property of J.& M. Magee | Wendell, E.J., lands. arch. | Montgomery Co., Pa. | 1914 | ||||
| PEW.RHS.2.30 | Sample | 3 | [select property plans for estates in Tredyffrin Township, Pa.] | Yerkes, Milton R., C.E. Yerkes Engineering Company | Includes the following estates: John Palmer, dec'd. (1903), A.J. Drexel Paul (1929), and Box Hill Corp. | 1903-1962 | ||||
| PEW.RHS.2.31 | Sample | 14 | [Select plans for estates in Radnor Township, Pa.] | Yerkes Engineering Company, Boler and Pagans | Estates: C.C. Rowle (1873), C.C. Harrison, E.P. Rawle, M.D. Carr, M.S.F. Biddle, C.F. Hoffman, Flanigen & Flanigen, M. Mott, B.S. Mott, B.S. Balch, G.H. McFadden, J. Rawle, and H.B.W. Hoffman, J.T. D'Arcy, W.C. Graham, H.H. Stout, A.L. McFadden(1950). | 1873-1950 | ||||
| PEW.RHS.2.32 | Sample | 21 | [Property plans for estates in Radnor Township, continued] | Barton and Martin; Sibley, William | Radnor, Pa. | Estates: E.R. Clifford (1951), F.H. Jackson, J. Myers, M.W.J. Graham, J. Birdsall, C.R. Lange, I.H Francis, F.W. Warner, and L.F. Stone(1960). | 1951-1960 | |||
| PEW.RHS.2.33 | Sample | 2 | Development map of property situated at Ithan, Radnor Township | Yerkes, M.R., C.E. | Key prop. names: Willcox, Levering, Maguire, Davis, Mellor, Ehret, Lagarus, Pepper, Lathrop, Forbes, McKean, Rush, Hollingsworth, Ashmead, Long, Hewson, Field, Morris, Sayen, McCaroley, Wiley, Douglas, Bether, Chandler, Griswold, Atterbury, & Montgomery. | 1924 | ||||
| PEW.RHS.2.34 | Sample | 3 | Plans of St. Davids Heights, Radnor Township | Rogers, Alva L., C.E. | Iven Ave., Conestoga Rd. | Other Key names included on the plan: Field, Lathrop, Wayne Co., and McClellan. | 1923 | |||
| PEW.RHS.2.35 | Sample | 15 | [Property plans for the Chew Estate, Radnor] | Yerkes, Milton R. C.E. Yerkes, J.B., C.E. | Lancaster Ave., Radnor, Pa. | Includes the following estates: Martha M. Brown and Mary J.B.Chew (1912, 1914, and 1919), Oswald Chew (1923, 1926, 1942, and 1944) Chew Estate (1939 and the same annotation 1954) | 1912-1954 | |||
| PEW.RHS.2.36 | Sample | 16 | [Property plans for Wynnewood Manor] | Warner, Robert A.; Allbright and Mabus | Smith, Walter B., dev. | Wynnewood Manor | Major streets: Wynnewood Ave.,Manor Rd., Montgomery Ave., and McClenahan Road. Includes a price list for properties. |
1906-1928 | ||
| PEW.RHS.2.37 | Sample | 18 | [Property plans for Wynnewood Manor] | Warner, Robert A.; Allbright and Mabus | Smith, Walter B., dev. | Wynnewood Manor | 1906-1928 | |||
| RHS.2.38 | Sample | 2 | Plan of Steam Mains, Wayne Steam Heat Co. | Wayne Steam Heat Co. | Wayne, Pa. | Wayne, St. Davids | 1930 | |||
| RHS.2.39 | Sample | 1 | Sanitary Sewerage System, Radnor Township | Charles F. Mebus, Engineer | Radnor Township, Delaware County, Pa. | 1931, 1933 | ||||
| RHS.2.40 | Sample | 1 | Wynnewood - Rough sketch showing location of remaining land developed and for sale | Smith, W. Gordon | 1926 | |||||
| RHS.2.41 | Sample | 1 | Radnor Township, Delaware County, Pa. | Radnor Township Engineering Department | Radnor Township, Delaware County, Pa. | 1941, 1949 | ||||
| PEW.RHS.3.1 | Specifications for a storage building for Wayne Iron Works, Wayne, Pa. | |||||||||
| PEW.RHS.3.2 | Specifications for a residence and garage for John F. Jacoby, Jr. | Adams, Alexander Mackie | Woodbine Ave, Lower Merion, PA | 1926 | ||||||
| PEW.RHS.3.3 | Specifications for an Ice Plant Building | Green, Van Rensselaer, C.E. (New York City) | Bryn Mawr Ice Company | 229 Willow Avenue, Wayne PA 19087 | 1924 | |||||
| PEW.RHS.3.4 | Specifications for alt. and add. to a house for George S. Munson, Overbrook | Willing, Sims, and Talbutt | Munson, George S. | Overbrook, Philadelphia, Pa. | ||||||
| PEW.RHS.3.5 | Specifications for retaining wall in Garden of John Jacobs | Bryn Mawr, Pa. | 1927 | |||||||
| PEW.RHS.3.6 | Letter to Walter B. Smith, April 1916, regarding utility sewer on Brookhurst Ave. | Yerkes, Milton R. | ||||||||
| PEW.RHS.3.7 | Specifications for heating system for a residence | American Radiator Heating System | 1935 | |||||||
| PEW.RHS.3.8 | Specifications for box stalls, to be erected for Bryn Mawr Horse Show Association | Lengel, J.D., bldr. | Bryn Mawr, Pa. | 1931 | ||||||
| PEW.RHS.3.9 | Smith, Walter Bassett [Rent reciept] | Wynnewood, Pa. | 1918 | |||||||
| PEW.RHS.3.10 | Suburban and Wayne Times [Newspaper], March, 1972. "Few Benefits for Radnor in proposed interchange."- Newspaper article and graphic plan showing and discussing expressway interchange with properties affected. | |||||||||
| PEW.RHS.3.11 | Specifications for alterations and addition to house for Thomas S. Ellis, IV | Edwards, E. Nelson | West Chester, Pa. | 1940 | ||||||
| PEW.RHS.3.12 | [Index cards, ca.1930] Cards first list Smith's drawing collection (listings correspond with numbers on red/white labels on lower right hand corner of sheets), then by client and communities, the names of architects and others (often abbreviated) are also included. | Smith, Walter B., dev. | ||||||||
| PEW.RHS.3.13 | Specifications for the James P. Lengel house | Lengel, James P. | Phoenixville, PA | 1927 | ||||||
| PEW.RHS.3.14 | [Ledger book, ca. 18851897]; One volume, includes construction and building costs for properties built in various communities in and around Philadelphia, including Center City, Wayne, Haverford, St. Davids, and Overbrook. | Wendell and Smith, bldr. | ||||||||
| PEW.RHS.3.15 | Specifications for the heating system of the J.D. Lengel Residence. | Warren & Webster | ||||||||
| PEW.RHS.3.16 | Specifications for repairs to garage for G.L.S Jameson, St. Davids, PA | Jameson, G.L.S. | St. Davids, Pa. | |||||||
| PEW.RHS.3.17 | Specifications for Chicken house and tool shed for Percy Colket | Lengel, J.D., bldr. | ||||||||
| PEW.RHS.3.18 | Specifications for Storage shed and garage for Valley Forge Chemical Mfg. Co. | King of Prussia, Pa. | 1924 | |||||||
| PEW.RHS.3.19 | Revised specifications for plumbing fixtures for Charles F. Conn Residence, St. Davids, PA | DeArmond, Ashmead & Bickley | Conn, Charles F. | St. Davids, Pa. | 1922 | |||||
| PEW.RHS.3.20 | Schedule of hardware for Apartment House for J. Frazier Bard, Wayne, PA | Penn's Hardware Company | Bard, J. Frazier | Bloomingdale Avenue, Wayne, Pa. | ||||||
| PEW.RHS.3.21 | Specifications for general work for an Apartment House for J. Frazier Bard | Boyd, Abel & Gugert | Bloomingdale Avenue, Wayne, Pa. | Work #1533 | ||||||
| PEW.RHS.3.22 | Specifications for Alterations and Additions to Spread Eagle Inn, Lancaster Avenue, Strafford, PA for Francis H. Diament and J.D. Lengel | DeArmond, Ashmead & Bickley | 1942-1943 | |||||||
| PEW.RHS.3.23 | Specifications for alterations to residence for C.W. Bayliss, Wayne, PA | Street, J. Fletcher | Bayliss, C.W. | Wayne, Pa. | 1926 | |||||
| PEW.RHS.3.24 | Specifications for a Garage building for Brookmead Guernsey Dairies, Inc. | Smedley, Walter | Brookmead Guernsey Dairies, Inc. | Wayne, Pa. | 1928 | |||||
| PEW.RHS.3.25 | Specifications for 6 three-story frame houses for Walter B. Smith, Narberth, PA | Reeser, Victor | Smith, Walter B., dev. | Narberth, Pa. | 1918 | |||||
| PEW.RHS.3.26 | Specifications for a house for Charles F. Conn, St. Davids Road, St Davids, PA | DeArmond, Ashmead & Bickley | St. Davids Road, St Davids, Pa. | 1921 | ||||||
| PEW.RHS.3.27 | Specifications for a two story residence for Mrs. Anna M. Fox | Fox, Mrs. Anna M. | Wayne, Pa. | |||||||
| PEW.RHS.3.28 | Specifications for bungalow for Mr. and Mrs. Paul J. Davis | Lengel, J.D., bldr. | Davis, Mr. and Mrs. Paul J. | Berwyn, Pa. | ||||||
| PEW.RHS.3.29 | Revised specifications for a garage for Frank R. Savidge | Boyd, Coneys, and Abel | Savidge, Frank R. | Devon, Pa. | Work #892 | 1914 | ||||
| PEW.RHS.3.30 | 6 | Specifications for a garage for Paul L. Lewis, Strafford, PA 1929 | J. Fletcher Street | Lewis, Paul L. | Strafford, Pa. | 1929 | ||||
| PEW.RHS.3.31 | 52 | Specifications for a convalescent hospital in Broomall, PA 1928 | Arthur H. Brockie | Broomall, Pa. | 1928 | |||||
| PEW.RHS.3.32 | 6 | Specifications for House #36, Cynwyd, PA | Frank Seeburger | Cynwyd, Pa. | ||||||
| PEW.RHS.3.33 | 22 | R.C. Hunter & Bro., Specifications for Design A-61 | Design A-61 | |||||||
| PEW.RHS.3.34 | 13 | Specifications for House #36, Cynwyd, PA | Frank Seeburger | Cynwyd, Pa. | ||||||
| PEW.RHS.3.35 | 3 | Specifications for alterations and additions to Miss Emma R. Harrar residence, Berkley Rd, Devon, PA | Louis H. Rush | Harrar, Emma R. Harrar | Berkley Rd, Devon, Pa. | |||||
| PEW.RHS.3.36 | 2 | Specifications for a concrete block house at St. Davids, PA | St. Davids, Pa. | |||||||
| PEW.RHS.3.37 | 1 | Radnor Realty Company, Willow Burn, "The Main Line's latest and best development at Villa Nova" - Publicity booklet including elevations, floor plansand costs. | Willow Burn | |||||||
| PEW.RHS.3.38 | 12 | Specifications for a house for Mr. C.H. Wetzel, Wayne, PA 1919 | Boyd, Abel & Gugert | Wetzel, C.H. | Wayne, Pa. | 1919 | ||||
| PEW.RHS.3.39 | 4 | J.D. Lengel, James Spear Stove and Heating Company, Specifications for hot water system, Residence on Farriston Road, Wayne, PA 1936 | Lengel, J.D., bldr. | Fariston Rd., Wayne, Pa. | 1936 | |||||
| PEW.RHS.3.40 | 5 | J.D. Lengel, Specifications for heating for Residence #30A, Berwyn, PA; J.D. Lengel, Work #30, Specifications for the construction of a two-story dwelling, Berwyn, PA | Lengel, J.D., bldr. | Berwyn, Pa. | ||||||
| PEW.RHS.3.41 | 3 | Defense Housing Project, War Production Board, Preference Rating Order #P-55, J.M. Lengel, 1942 | 1942 | |||||||
| PEW.RHS.3.42 | 4 | War Production Board, War Housing Manual, 12/2/1942; Priorities Regulation No. 1, 12/23/1941; Defense Housing Critical List, 2/24/1942; Projects Requirements Plan, n.d. | 1942 | |||||||
| RHS.3.43 | 7 | Specifications for Five single houses at Rosemont, Va., for the Rosemont Development Co. | Rosemont Development Co. | Rosemont, Va. | ||||||
| RHS.3.44 | 10 | Specifications for alterations to residence at Wayne, Penna., for Mr. C.W. Bayliss | Street, J. Fletcher | Bayliss, C.W. | Wayne, Pa. | 1926 | ||||
| RHS.3.45 | 28 | Specifications: Alteration & Addition to a house at St. Davids Penna. for Dr. O.H.P. Pepper | Willing, Sims & Talbutt | Pepper, Dr. O.H.P. | St. Davids, Pa. | |||||
| RHS.3.46 | 5 | Specifications for three story twin house for Jonathan M. Lengel on Lenoir Avenue, Wayne, Pa. | Boyd, D. Knickerbacker | Lengel, J.D., bldr. | Lenoir Avenue, Wayne, Pa. | |||||
| RHS.3.47 | 4 | Specifications for two story, two family apartment house on Bloomingdale Avenue, Wayne, Penna. for Miss Helen S. Johnson and Mrs. Anna J. Bard | Boyd, Abel & Gugert | Bard, Mrs. Anna J. | Bloomingdale Avenue, Wayne, Pa. | |||||
| RHS.3.48 | 11 | Schedule of Hardware. - Residence & Garage for John F. Jacoby Jr., Woodbine Ave. North of Montgomery Ave., Lower Merion | Adams, A.M. | Lengel, J.D., bldr. | Jacoby, John F., Jr. | Woodbine Ave. North of Montgomery Ave., Lower Merion | ||||
| RHS.3.49 | 2 | Schedule of Hardware, Roger Warner Residence, Wayne, Pa. | Wallace & Warner | Lengel, J.D., bldr. | Warner, Roger | Wayne, Pa. | ||||
| RHS.3.50 | 2 | Copy of specification for millwork, for operation #664, to be built on Harrison Road, Ithan, Penna., for Mr. A.W. Canizares, Wayne, Penna. J.D. Lengel, builder. | Lengel, J.D., bldr. | Canizares, A.W. | Wayne, Pa. | |||||
| RHS.3.51 | 29 | Specifications for Store and apartment building For Mr. George L. Harrison | Harrison, George L., Jr. | 124 East Lancaster Avenue, Wayne, Pa. | 1928 | |||||
| RHS.3.52 | 18 | Broomell System - Specifications, Vapor Heating Co. - No. P&S 12532, Wayne Methodist Episcopal Church Audubon & Runnymeade Avenue Wayne, Pa. | Wayne Methodist Episcopal Church | Audubon & Runnymeade Avenue Wayne, Pa. | 1927 | |||||
| RHS.3.53 | 10 | Specifications for Five single houses at Rosemont, Va. for the Rosemont Development Co. - Houses No. 102 & 674 | Rosemont Development Co. | Rosemont, Va. | ||||||
| RHS.3.54 | 5 | Schedule of Russwin distinctive hardware - Store and Apartment for George L. Harrison Jr. Wayne Penna. | MacKenzie & Wiley | Lengel, J.D., bldr. | Harrison, George L., Jr. | Wayne, Pa. | ||||
| RHS.3.55 | 5 | Specifications of the workmanship and materials required for the erection of a house for Mr. F.H. Treat, and Mr. Jerry Manzi, at Wayne Penna. According to plans No. 106-A. | Treat, Frederick H. and Manzi, Jerry | Wayne, Pa. | ||||||
| RHS.3.56 | 6 | General specifications for small house (work no. 588) at Wayne, Penna. for Mr. Frederick H. Treat. | Boyd, D. Knickerbacker | Treat, Frederick H. | Wayne, Pa. | |||||
| RHS.3.57 | 7 | Specifications for alterations & additions to the residence of T. Truxton Hare. | Rush, Louis H. | Hare, T. Truxton | Weadley Road, Radnor, Pa. | 1927 | ||||
| RHS.3.58 | 8 | Specifications for alterations & additions to the residence of T. Truxton Hare | Rush, Louis H. | Hare, T. Truxton | Weadley Road, Radnor, Pa. | 1927 | ||||
| RHS.3.59 | 6 | Schedule for Hardware, Residence for Arlington W. Canizares | Lengel, J.D., bldr. | Canizares, Arlington W. | Harrison Road, Ithan, Pa. | 1931 | ||||
| RHS.3.60 | 1 | Alterations - The LeRay E. Dale Job, 421 Woodland Ave., Wayne, Penna. | Lengel, J.D., bldr. | Dale, LeRay E. | Wayne, Pa. | |||||
| RHS.3.61 | 13 | Specifications for house no. 197 for Norman P. Sinclair, Wayne, Pa. | Lengel, J.D., bldr. | Sinclair, Norman P. | Wayne, Pa. | |||||
| RHS.3.62 | 21 | Specifications for alterations and additions to residence of Mr. Roger Warner at Wayne, Pennsylvania Commission #545 |
Wallace & Warner | Warner, Roger | Wayne, Pa. | |||||
| RHS.3.63 | 3 | Specifications for the Kernerator incinerator, John Jacoby residence, J.D. Lengel, 103 W. Lancaster Ave., Wayne, Pa. | Lengel, J.D., bldr. | Jacoby, John | Wayne, Pa. | |||||
| RHS.3.64 | 9 | Specifications for alterations to residence at Wayne, Penna. for Mr. Charles W. Bayliss | Street, J. Fletcher | Bayliss, Charles W. | Wayne, Pa. | |||||
| RHS.3.65 | 5 | Schedule of Hardware, Dr. O.H.P. Pepper Residence, St. Davids, Pa. | Lengel, J.D., bldr. | Pepper, Dr. O.H.P. | St. Davids, Pa. | |||||
| RHS.3.66 | 3 | Specifications for rebuilding stone arch bridge on the Roberts Road between Conestoga Road and Ithan Creek Road | Roberts Road | 1925 | ||||||
| RHS.3.67 | 2 | Lumber list for Wayne house (unidentified) | Wayne, Pa. | |||||||
| RHS.3.68 | 8 | Specifications for Dairy Building, Wayne, Pa. for Brookmead Guernsey Dairies, Inc. | Smedley, Walter | Brookmead Guernsey Dairies, Inc. | Wayne, Pa. | 1923 |
